Zhejiang BC&TV Technology Co., Ltd.Zhejiang BC&TV Technology Co., Ltd.
|
Item
|
Units
|
Value
|
|
Wavelength
|
nm
|
1550±5
|
|
Output Power
|
dBm
|
1*5,1*6,1*7,1*8,1*9,2*5, 2*6,2*7,2*9
|
|
Optical Return Loss
|
dB
|
≥14
|
|
Connector
|
/
|
FC/APC Or SC/APC
|
|
Bandwidth
|
MHz
|
47-862
|
|
Input Level
|
dBmV
|
78
|
|
Flatness
|
dB
|
±2
|
|
Return Loss
|
dB
|
≥10
|
|
Input Impedance
|
Ohm
|
75
|
|
CNR*
|
dB
|
≥50
|
|
CTB*
|
dB
|
≤-60
|
|
CSO*
|
dBm
|
≤-60
|
|
SBS
|
dBm
|
≥16.0 13,16,18
|
|
Power Supply
|
VAC/VDC
|
110～265/ -48
|
|
Power Consumption
|
W
|
≤50
|
|
Working Temperature
|
℃
|
0～50
|
