1. Adopts high-linearity, DFB laser with low noise,1550nm wavelength.
2. Transmission distances:≤20km
3. AGC and MGC function
4. High Reliability with excellent performance
|
Item |
Units |
Value |
|
Optical and RF Parameters |
||
|
Wavelength |
nm |
1550±5 |
|
Connector Type |
/ |
FC/APC or SC/APC |
|
Bandwidth |
MHz |
47-862/1002 |
|
RF Input Return Loss |
dBm |
≥16(47-550MHz); ≥14(550-1002MHz) |
|
RF Input Level |
dBuV |
80±5 |
|
Flatness |
dB |
≤±0.75 |
|
CNR |
dB |
≥51dB |
|
CSO |
dB |
≥65dB |
|
CTB |
dB |
≥60dB |
|
General Parameters |
||
|
Power Supply |
VAC/VDC |
220VAC±10% |
|
Power Consumption |
W |
≤27 |
|
Working Temperature |
C |
-20~85 |
