1.Design for FTTB and RFoG networks
2.High output level with AGC function
3.Digital LED control and adjustment
4.“Burst mode” and “Normal mode” button switch
|
Performance |
Parameter |
Remark |
|||||
|
Min. |
Typ. |
Max. |
|||||
|
Forward
Path |
Wavelength |
(nm) |
1200 |
|
1620 |
|
|
|
Input Power |
(dBmW) |
-8 |
|
+2 |
|
||
|
Frequency* |
(MHz) |
87 |
|
1000 |
* 85MHz,54MHz optional |
||
|
Output Level |
(dBmV) |
98 |
100 |
|
@1000MHz |
||
|
EQ Degree |
(dB) |
|
6 |
|
87MHz to 1G |
||
|
C/N |
(dB) |
|
51 |
|
-1dBm@PAL 98 Chanel
type testing |
||
|
CSO |
(dB) |
|
60 |
|
|||
|
CTB |
(dB) |
|
65 |
|
|||
|
Return Loss |
(dB) |
14 |
16 |
|
87-550MHz≥16
550-1000MHz≥14 |
||
|
Return
Path |
Wavelength |
(nm) |
|
1310 |
|
|
|
|
Input Power |
(mW) |
|
1 |
|
|
||
|
Frequency |
(MHz) |
25 |
|
65 |
*42MHz optional |
||
|
RF Input Level |
(dBmV) |
|
90 |
|
|
||
|
Flatness |
(dB) |
|
0.75 |
|
|
||
|
Return Loss |
(dB) |
16 |
|
|
|
||
|
Power at which optical turn ON |
(dB) |
|
56.5 |
|
@-15 test |
||
|
Power at which optical turn OFF |
(dB) |
|
45.5 |
|
@-15 test |
||
|
Time to 90％ optical ON |
(ms) |
|
0.85 |
|
|
||
|
Time for optical falls to 10％ |
(ms) |
|
1.3 |
|
|
||
|
General |
PS |
DC |
(V) |
|
5 |
|
|
|
Consumption |
(W) |
|
4.5 |
|
|
||
|
Working Temperature |
(℃) |
-25 |
|
+65 |
|
||
|
Humidity |
(℃) |
5 |
|
95 |
|
||
|
|
Dimension |
(mm) |
178×136×36 |
(W)×(D)×(H) |
|||
|
Net Weight |
(kg) |
0.5 |
|
||||
