1.Design for FTTB and RFoG networks
2.High output level with AGC function
3.Digital LED control and adjustment
4.“Burst mode” and “Normal mode” button switch
|
Items |
Units |
Value |
Remark |
||||
|
Min. |
Typ. |
Max. |
|||||
|
Forward Path |
Wavelength |
(nm) |
1200 |
|
1620 |
|
|
|
Input Power |
(dBmW) |
-8 |
|
2 |
|
||
|
Bandwidth* |
(MHz) |
87 |
|
1002 |
*85MHz,54MHz optional |
||
|
Output Level |
(dBμV) |
|
98 |
100 |
@1002MHz |
||
|
EQ Degree |
(dB) |
|
6 |
|
87MHz to 1G |
||
|
C/N |
(dB) |
|
51 |
|
-1dBm@PAL 98 Chanel type testing |
||
|
C/CTB |
(dB) |
|
60 |
|
|||
|
C/CSO |
(dB) |
|
65 |
|
|||
|
Return Loss |
(dB) |
14 |
16 |
|
87-550MHz≥16 550-1002MHz≥14 |
||
|
Return Path |
Wavelength |
(nm) |
|
1310 |
|
|
|
|
Input Power |
(mW) |
|
1 |
|
|
||
|
Frequency |
(MHz) |
25 |
|
65 |
*5~42MHz optional |
||
|
RF Input Level |
(dBμV) |
|
90 |
|
|
||
|
Flatness |
(dB) |
|
0.75 |
|
|
||
|
Return Loss |
(dB) |
14 |
16 |
|
|
||
|
Power at which optical turn ON |
(dBμV) |
|
72 |
|
|
||
|
Power at which optical turn OFF |
(dBμV) |
|
68 |
|
|
||
|
Time to 90％ optical ON |
(μs) |
|
0.85 |
|
|
||
|
Time for optical falls to 10％ |
(μs) |
|
1.3 |
|
|
||
|
General Parameters |
PS |
DC |
(V) |
|
5 |
|
|
|
Consumption |
(W) |
|
4.5 |
|
|
||
|
Working Temperature |
(℃) |
-25 |
|
65 |
|
||
|
Humidity |
(℃) |
5 |
|
95 |
|
||
|
Dimension |
(mm) |
178×136×36 |
(W)×(D)×(H) |
||||
|
Net Weight |
(kg) |
0.5 |
|
||||
