Power ON/OFF controlled by computer
Each output and total output controlled by computer
Modulation Degree ON/OFF controlled by computer
Working Status Protection
Remote Control
| RF Parameters | ||
| Item | Units | Value |
| Working Frequency | MHz | 48-862 |
| Frequency Accuracy | kHz | ±10 |
| Frequency Total Deviation | kHz | ±50 |
| Out-of-band Rejection | dBc | ≥80 |
| Max Output Level | dBmV | ≥95 |
| Single Output Attenuation | dB | ≥10 |
| Step | dB | ≤0.1 |
| Total Output Attenuation | dB | 40 |
| Step | dB | 1 |
| Output Impedance | W | 75 |
| Modulation Degree | ≥99.4 %(TURN ON) | |
| Phase Noise | dBc/Hz | ≤-85(10kHz) |
| dBc/Hz | ≤-100(100kHz) | |
| Modulation Signal Parameters | ||
| Inner Line Frequency | Hz | 15625 |
| Frequency Accuracy | Hz | ±2 |
| External Line Frequency Input: TTL Level | ||
| Other Parameters | ||
| Working Voltage: | AC | 220V±10% |
| 50Hz±5% | ||
| Apparent Power | VA | 520 |
| Packing Information | ||
| a. Weight: | kg | 155 |
| b．Dimension(mm): | (W)x(D)x(H) | 595x550x1400 |
| Environment | ||
| Working Temperature | ℃ | 10~30 |
| Relative Humidity | RH | (20-75)% |
| Limited Temperature | ℃ | 0~40 |
| Storage Temperature | ℃ | -40~60 |
