1. 1U standard rack mounted case
2. High-linearity & low-noise DFB laser
3. APC and ATC circuitb
4. Backlight LCD shows all the parameters
5. The operation status can be monitored by network management software(web browser)
|
Items |
Units |
Value |
|
Bandwidth |
MHz |
47~750/862/1002 |
|
Flatness |
dB |
±0.75 |
|
Return Loss |
dB |
≥16 (47~550MHz); ≥14 (550~750/862MHz) |
|
Input Impedance |
Ω |
75 |
|
Input level |
dBμV |
80±5 (AGC) |
|
OMI |
dB |
±5 |
|
Optical Wavelength |
nm |
1310±20 |
|
Optical Power |
mW |
4~24 (optional) |
|
C/CTB |
dB |
≥65 |
|
C/CSO |
dB |
≥60 |
|
C/N |
dB |
≥51 |
|
Optical Connector |
/ |
SC/APC or FC/APC |
|
Optical fiber Type |
/ |
Single Mode |
|
Voltage |
V |
220±10% |
|
Weight |
kg |
≤6 |
|
Dimension: |
mm |
484*381*44 (W*D*H) |
|
Model |
Description |
|
ZBL5111TC-A6.3 |
Optical Transmitter,47~750/862/1002MHz ,1310nm, Optical power≥6.3mW,Dual Power Supply 04 input /04 output |
|
ZBL5111TC-A20 |
Optical Transmitter,47~750/862/1002MHz ,1310nm, Optical power≥20mW,Dual Power Supply 04 input/04 output |
